Discover datacenters / Germany
Pfalzkom DCRN II
Pfalzkom GmbH · Mutterstadt · Regional Germany · Germany
- Design resilience tier
- III
- Redundancy (as published)
- High redundancy of the electrical supply: two low-voltage main distributions; two transformers; two UPS systems (A = n+1, B = n+1), in two rooms each separated from the batteries; two standby power plants: diesel generator and prepared connections for further temporary generators. 20 kV medium-voltage feed, fully redundant, directly from the substation, independent of the distribution grid. Four server rooms as separate fire compartments at full build-out. Separate fire compartments in consistent F90 quality. High-availability class 3+; TÜV-tested. Guaranteed minimum availability: 99,98 % per year. Both data centres are connected with multiple redundancy to the own fibre network with all major exchange nodes as well as via various carriers. Integration into the PFALZKOM fibre network with redundant and high-performance connection to several internet exchange nodes.
- Floor area
- 2,340 m² whitespace
- Rack density
- 12 kW
Platform reviewed · 04 Sept 2026 · Recent
- Density (as published)
- 19" IT rack, W/D: min. 700 / min. 1000 mm; at least 45 usable rack units; 2 power circuits with at least 24 IEC C13 sockets; power draw (by arrangement up to 12 kW). Optional services: extra-deep rack (1200 mm); increase of the connected load on application and after technical review, generally within 4 weeks. (service sheet Rack DCRN II, ServiceID SRV02002, as of 19-01-2026). Example calculation on the location page: 45 usable rack units; two power circuits with at least 24 IEC C13 sockets; power draw up to 3 kW (expandable to up to 12 kW); mechatronic locking. Cage example: with space for six customer-owned racks, including 18 kW connected load.
- Cooling
- Air and indirect cooling, Free cooling
- Availability
- Availability on request
Imported · Recorded 08 Jun 2026 · Not recent
- Cross-connect
- On request
- Renewable power
- 100% renewable power
- Design PUE
- Design PUE 1.2 to 1.4
- PUE note
- PUE below 1.3, with ongoing optimisation.
- Services
- Colocation, connectivity and cloud and managed services
- Certifications 7
- ISO 27001ISO 9001ISO 50001ISAE 3402EN 50600Climate Neutral Data Centre PactTÜV-geprüft (Hochverfügbarkeitsklasse 3+)
